Product Series

Six product series

All products ZC / CCS certified.

DMA Series (22–38)

Used for weighing anchor, dropping anchor and mooring.

DMJ Series (24–38)

Front / rear winch configurations…

DMA-J / S / D Series

Anchoring, dropping and mooring in one.

CWZ / CWL Series

Centrifugal and self-priming pumps.

JD-1.5H

Acoustic signalling unit for 20–200 m vessels.

CZ Series

Cabin ventilation, cast-aluminium impeller.

Technical parameters at a glance

Excerpt of selected DMA-series windlass parameters.

Model	Chain Ø (mm)	Hoist speed (m/min)	Anchor depth (m)	Working load (kN)	Rated power (kW)
DMA22-2-45	22	≥9	≤45	15.7	7.5 / 5
DMA24-2-45	24	≥9	≤45	18.7	11 / 7
DMA26-2-45	26	≥9	≤45	22.0	11 / 7
DMA28-2-45	28	≥9	≤45	25.48	11 / 7
DMA30-2-45	30	≥9	≤45	29.25	17 / 11
DMA32-2-45	32	≥9	≤45	33.28	17 / 11
DMA34-2-45	34	≥9	≤45	37.57	17 / 11
DMA36-2-45	36	≥9	≤45	42.12	17 / 11
DMA38-2-45	38	≥9	≤45	46.93	22 / 22 / 16

All marine products ZC / CCS approved.

Type-approval certificates from Guangxi Ship Inspection Bureau.

CCS

Certified by China Classification Society.

★

Establish a world-renowned brand.

🛡

Every unit ships with a unique serial number.
